技术参数 Technical Parameters
工作频率Working frequency (KHz)：19-25
功率Power（W）：连续可调 1—100％ Continuously adjustable 1-100%
显示方式Display mode：4.3 寸彩屏（可选配触摸屏） 4.3-inch color screen (touch screen optional)
显示内容Display content：时间、功率、温度、实时频率 等 time, power, temperature, real-time frequency, etc.
占空比Duty cycle：0.1—99 ﹪
破碎容量Crushing capacity (ML)：0.5---1200
可选配变幅杆Optional horn：￠ 2. 3 . 6 . 8. 10 .12. 15 . 20 .25 或可定制 存储数据：18 组
￠ 2. 3 . 6 . 8. 10 .12. 15 . 20 .25 or can be customized
报警：超温、过流、过载 Alarm: over temperature, overcurrent, overload
定时（分钟）Timing (minutes):：0----999
工作模式：间隙 连续 Working mode: gap
温度报警（℃）Continuous temperature alarm (℃)：0—99
重量 + 外形尺寸Weight+ Dimensions：3.8kg +166*300*220（长 * 宽 * 高）(length* width* height )
电源Power supply：220V/50Hz
产品特点Features
数字化集成 digital integration
全数字化集成电路，振幅输出稳定一致 Fully digital integrated circuit, stable and consistent amplitude output
内置照明测温Built-in lighting temperature measurement
内置照明及测温装置系统Built-in lighting and temperature measuring device system
一体化Integration
一体机，超声波电源及隔音箱融为一体，节省空间
All-in-one machine, ultrasonic power supply and soundproof box are integrated to save space
24 小时 24 hours
可 24 小时连续工作，稳定可靠 Can work continuously for 24 hours, stable and reliable
电动升降 Electric lift
换能器电动升降，方便样品的拿进拿出The transducer is electrically lifted and lowered to facilitate the entry and exit of samples
转换效率Conversion efficiency
电功转换效率高且始终一致 High and consistent power conversion efficiency
